1. Product Overview – Engineered for Safety, Designed for Versatility
The A2 FR Aluminium Composite Panel (ACP) is a premium sandwich panel engineered with a mineral-filled, fire-retardant core containing over 90% non-combustible materials, laminated between two high-quality aluminium sheets.
This panel represents the highest non-combustible classification currently achievable for composite materials. Yet it retains all the practical advantages of standard aluminium composite panels—including lightweight construction, excellent flatness, a wide range of finishes, and ease of fabrication and installation.
2. Fire Performance – Certified Non-Combustible
When it comes to fire safety, the A2 FR ACP sets the benchmark. It has been rigorously tested and complies with:
- EN 13501-1 – Classified as A2-s1-d0 (non-combustible, minimal smoke emission, no flaming droplets)
- BS 476 Part 4 – Certified as non-combustible under this British standard
These certifications confirm that the material will not ignite and will not release toxic black smoke during a fire—critical factors that provide valuable evacuation time and significantly reduce risks to life and property.
3. Technical Specifications – Built to Your Project Requirements
| Parameter |
Available Options |
| Panel Thickness |
3 mm, 4 mm, 6 mm (custom sizes available upon request) |
| Aluminium Skin Thickness |
0.2 mm – 0.5 mm |
| Aluminium Alloy |
1100, 3003, 5005 (optional per customer preference) |
| Core Composition |
Mineral-filled flame-retardant core (>90% inorganic minerals) |
| Panel Width |
1000 mm – 2000 mm (common sizes: 1000, 1220, 1250, 1500, 1575 mm) |
| Panel Length |
2440 mm, 3200 mm, 4880 mm, 5800 mm, or custom cut-to-size |
| Surface Coating |
PVDF, FEVE, or PE (Polyester) coating – with excellent weather resistance and color consistency |
4. Why Choose A2 FR Aluminium Composite Panel?
- Unmatched Fire Safety
As a non-combustible material, A2 FR ACP will not ignite or generate hazardous smoke in a fire. This buys crucial time for occupant evacuation, reduces injury and casualty risks, and minimises property damage.
- Lightweight Yet Strong
Compared to solid aluminium panels of the same thickness, A2 FR ACP is significantly lighter. For example, a 4 mm A2 FR panel is approximately 20% lighter than a 4 mm solid aluminium sheet—reducing structural load and simplifying transportation and installation.
- Easy to Fabricate & Install
No special equipment is required. The panel can be cut, grooved, drilled, and bent using standard CNC machinery—just like standard ACP—making it contractor-friendly and cost-effective.
- Superior Surface Quality
The roller-coated finish is smooth, uniform, and colour-consistent across production batches, ensuring a clean, professional look for any façade or interior application.
5. Applications – Where High Fire Safety Standards Are Mandatory
The A2 FR Aluminium Composite Panel is the material of choice for projects demanding the highest level of fire protection, including:
- High-rise buildings and skyscrapers
- Shopping malls and commercial complexes
- Metro stations and airport terminals
- Public institutions, hospitals, and educational facilities
In short, wherever people gather and safety regulations are strict, A2 FR ACP delivers proven performance.
6. Customization & Support
We understand that every project has unique specifications. We offer flexible customisation in dimensions, alloy grades, coating types, and colours to match your architectural vision—without compromising on fire performance.
